German Industry Standard Fish plate

Standard: DIN5902-1995

Material: Chinese steel grade Q235 or Chinese steel grade Q295

Size: Fl10, Fl14, Fl18, Fl20, Fl30, Fl33, Fl41-49, Fl41-54

Chemical Compositon (Fl10 - Fl20,Q235)

C           Mn          Si          S          P

0.14-0.22 0.30-0.65 ≤0.30 ≤0.050 ≤0.045

Mechanical Property (Fl10 - Fl20)

Tensile strength R_m : ≥375 Mpa

Yield strength R_eL / R_r0.2: ≥235 Mpa

Elongation A : ≥21%

Chemical Compositon (Fl30 - Fl41-54, Q295)

C           Mn          Si          S          P

0.52-0.60    0.50-0.80     0.17-0.37 ≤0.035     ≤0.035

Mechanical Property (Fl30 - Fl41-54)

Tensile strength R_m : ≥390 Mpa

Yield strength R_eL / R_r0.2: ≥295 Mpa

Elongation A : ≥23%
